Used in :Cakes, bread, biscuits, cookies, dumplings, buns, etc., snack food, fresh fruits and vegetable medical care
Application
It is suitable for packaging various solid and reqular-shaped items such as baked and quick-frozenfood,cakes, bread, biscuits, cookies, dumplings, buns, etc., snack food, fresh fruits and vegetable medical care, daily necessities and hardware, electronic appliances, sanitary products, and household paper.
Technical specification
Parameter | Double Jaws | Single Jaws |
Center distance (mm) | 132 | 150 |
Packing speed (bag/min) | 30-300 | 30-150 |
Bag size - Length (mm) | 60-500 | 60-500 |
Bag size - Width (mm) | 35-160 | 35-180 |
Bag size - Height (mm) | 5-50 | 5-70 |
Total power (KW) | 5.1 | 3.7 |
Power supply type | 1AC 220 50HZ/60HZ | 1AC 220 50HZ/60HZ |
Machine size (L × W × H) | 4000*900*1350 (Infeeding Conveyor) | 4000*900*1350 (Infeeding Conveyor) |
Packaging film width (mm) | 80-400 | 80-400 |
Machine weight (kg) | 350 | 350 |
Packaging film material | OPP/PVC/CPP/PTPE/KOP/CPP/Aluminum film etc. | |
Machine features
The horizontal sealing, middle sealing and feeding are all controlled by independent servomotors, with simple mechanical structure, stable operation and low noise:
Colored touch panel is equipped with self-developed operating system, which brings simple, intuitive and convenient operation with a qood human-machine interface.
It has a recipe parameter memory function, and the touch screen can save multiple sets of parameter configurations, which can be adjusted and used at any time without resetting;
The feeding speed is automatically tracked during wiring, and the flowpacm machine automatically accelerates and decelerates:
High precision and high speed.
